Cleanroom System Equipment

JC Bitsomang Eye Clinic Cleanroom System — Cleanroom, Sterilization Monitoring, Particle Counter

JC Bitsomang Eye Clinic Advanced Clean System

[]

Cleanroom

Sterilization Monitoring

Particle Counter

Prevention of Particle Generation

Prevention of Particle Accumulation

Prevention of Particle Infiltration

Clean Air Supply Maintenance of Optimal Temperature, Humidity, and Room Pressure

Prevention of Particle Retention

Cleanroom System

Sterilization Monitoring System

Particle Counter

A cleanroom refers to an enclosed space in which contamination control is strictly maintained. It is designed to control not only airborne particulate matter, but also environmental conditions such as temperature, humidity, indoor air pressure, gas composition, static electricity, micro-vibrations, and electromagnetic waves.The atmosphere contains a wide range of particles and microorganisms, including textile fibers, sand particles, metallic dust, skin flakes, tobacco smoke, bacteria, viruses, and fungi. These contaminants may increase the risk of infection or postoperative complications during surgery.

JC Bitsomang Eye Clinic has implemented cleanroom facilities and aseptic systems in accordance with internationally standardized JCI accreditation criteria, in order to manage invisible fine dust particles and microorganisms and help prevent postoperative infections at the source.

High-performance HEPA and ULPA filters installed in the ceiling purify contaminated air through a specialized filtration process and exhaust it through outlets located in the lower sidewalls of the operating room. These filters remove more than 99.9% of bacteria and viruses.In addition, clean zones and contaminated zones are strictly separated, and an air shower system is installed at the entrance of the operating room to block contaminated air and dust introduced from outside.

BI PCD, or Biological Indicator Process Challenge Device, is a sterilization monitoring device used to verify whether all microorganisms, including bacteria, have been effectively eliminated. It is used to confirm the success of the sterilization process and to evaluate sterilization efficacy.JC Bitsomang Eye Clinic is equipped not only with various high-pressure steam sterilizers, but also with an EO gas sterilization system. In addition, we have installed an ATTEST Incubator sterilization monitoring system to accurately verify whether sterilization has been properly completed, including sterilization using an EO gas sterilizer, HS-4085EO.

Through the sterilization monitoring system, samples collected from sterilized items are incubated at 37°C for 4 hours, after which fluorescence is automatically detected. This allows the sterilization status of each disinfected and sterilized item to be checked during every sterilization cycle.

Because confirmation of sterilization is essential in every disinfection and sterilization process, this system enables faster infection control through a shortened incubation time and is an essential component in establishing an aseptic medical environment.

A particle counter is a device that measures airborne particles and fine dust in the air, indicating the particle concentration within a specific space. It is an essential device for hospitals and clinics that operate cleanrooms, as it allows regular measurement of fine dust and airborne particulates and provides objective data for cleanroom maintenance and operational management.Although particle counters come in various types and forms, JC Bitsomang Eye Clinic uses the Extech VPC300. This portable device is easy to carry and allows quick and convenient measurement. Its LCD screen displays particle concentration reports, enabling continuous monitoring whenever necessary.

Aseptic Surgery System
Air Shower (2 units)
AIR SHOWER
A clean-up device that prevents external contamination when entering cleanrooms by using high-velocity clean air to remove dust and microbes from personnel before entry.
Preparation Room — Multi-method Sterilization System
Low-temperature Plasma Sterilizer
LOWTEM CRYSTAL
Low-temperature plasma sterilizer operating below 50°C — uniformly maintains material temperature while drying moisture, delivering consistent sterilization across conditions.
Large Capacity Autoclave
VSC-360L
A water-ejector vacuum system creates a deep vacuum (below -0.9 bar) inside the chamber, delivering complete sterilization and disinfection.
Large Capacity Autoclave
HS-5020
Uses 121–138°C steam to sterilize pathogens adhering to surgical instruments and other items.
EO Gas Sterilizer
HS-4085EO
Uses ethylene oxide gas — instead of liquid or solid agents — to sterilize bacteria, viruses, and other microorganisms.
Cassette Autoclave (3 units)
SCISCAN STATIM 2000
Uses 121–138°C steam to sterilize pathogens on surgical instruments and other items.
Autoclave
SCISCAN STATIM 5000
Uses 121–138°C steam to sterilize pathogens adhering to surgical instruments and other items.
Sterile Water Supply
HANDY 1000
Uses a flow-through UV lamp to generate and supply sterilized water for hand washing and instrument cleaning before and after surgery.
Sterilization Indicator Incubator
ATTEST INCUBATOR
An incubator that verifies EO sterilization — incubates at 37°C for 4 hours and automatically reads fluorescence to confirm a final negative (-) result.
Medical Blood Refrigerator
BPR245
Dedicated blood-storage refrigerator that preserves blood validity long-term per AABB standards. Maintains internal temperature precisely between 2–6°C via microprocessor real-time control, preventing degradation or freezing.
Air Sterilizer 165m² (6 units)
VIRUSKILLER VK101
Filters airborne pollutants and fine dust, then destroys pathogen DNA/RNA through a sterilization-and-purification module. Korea's first 99.99% air sterilizer effective against H1N1 influenza and a wide range of viruses and mold.
HEPA Air Purifier 165m² (2 units)
FA 502N
HEPA-based air purifier recommended for allergy care and prevention — features dual-sensor auto operation (dust + gas) and 360-degree airflow control (vertical/horizontal) to evenly distribute clean air. The FA502N (Figaro 502 Neutralizer) skin-protective system neutralizes the charge of indoor particulates, preventing them from adhering to skin (cosmetic benefit) and equipment surfaces — delivering ideal air cleanliness.
Operating Room — Last Safety System
Air Sterilizer 100m² (2 units)
VIRUSKILLER VK001
Filters airborne pollutants and fine dust, then destroys pathogen DNA/RNA through a sterilization-and-purification module. Korea's first 99.99% air sterilizer effective against H1N1 influenza and a wide range of viruses, bacteria, and mold. ※ Sterilization rate ≥ 99.999% against viruses, bacteria, mold, and spores (Virus, Bacteria, Molds, Spores) ※ VOC removal rate ≥ 90.000% (volatile organic compounds: formaldehyde, benzene, toluene, etc.) ※ Bad smell removal rate ≥ 90.000% (ammonia, nitrate compounds, etc.)
HEPA Air Purifier 165m² (2 units)
FA 602N
HEPA-based air purifier recommended for allergy treatment and prevention — dual-sensor auto operation (dust + gas) with 360-degree airflow control (vertical/horizontal) for even clean-air distribution. The FA502N (Figaro 502 Neutralizer) skin-protective system neutralizes the charge of indoor particulates, preventing them from adhering to skin (cosmetic benefit) and equipment surfaces — delivering ideal air cleanliness.
Plasmacluster Air Purifier 200m² (3 units)
SHARP FU360K
Plasmacluster air purifier covers 200m² and effectively removes influenza, bacteria, harmful substances, and mold throughout the room by emitting 20,000–100,000 positive (+) and negative (–) ions per second.
